Pre-Fabricated MEP Modular System

We developed an in-house prefabricated MEP modular system to improve efficiency and also proper control of the project operations by using BIM Technology. In addition, it is a pre-assembled and ready-to-install system with the same materials as the traditional method of installing single items one by one.

ADVANTAGES: Save 30% Time in MEP ProjectClash Free ServicesEnhanced workplace safety quality control & assuranceReduced material handling space at the site for storage & fabrication

ASSEMBLED Axial ducted fan NFDAX - 500 - 05 1.5 KW 460V 60HZ WITH FRD DUCT & FRD VCD (NAFFCO) Product Dimension 2m(l) x 0.8m(w) x 1.8m(h) WITH STAND 2m(l) x 1m(w) x 2 m(h)

Naffco Smoke Management System – Comprehensive Smart Engineering Solution Under One Unit Responsibility

Naffco provides a fully integrated and smart engineering solution for smoke management systems, designed to meet both local and international codes. This system is developed under a single unit responsibility, ensuring seamless coordination and optimal performance. It integrates UL-listed and certified equipment, including fans, ducts, dampers, and other essential components, all working together to provide a reliable and effective smoke management solution to keep all exit roots free of smoke helping the occupants to escape safely & protecting the fire fighters from Smoke during their duty.

Fire truck – Built on custom chassis

D-A411 Intelligent Photoelectric Smoke Detector is an addressable fire alarm device cooperating with SHIELD intelligent fire alarm control panels to build a fire detection system. It shows the fire alarm by LED indicators and transmits the fire signal to the control panel.

• Twin LED for 360° view.
• Electronically addressed in the field.
• Built-in microprocessor stores 14 history data.
• Drift compensation to suit the environment changing extensively.
• Self-diagnostic.
• Remote indicator output available.
• Complies with EN 54-7 standard.

Highlights

• DC Generators – PMG Technology
• Variable-speed Engine (LPG)
• Up to 68% Fuel saving with Renewable power
• Deep cycle batteries
• Plug & Play with renewable energy sources
• Armored and Anti-theft devices
• Upto Zero CO2 emissions

Characteristics

• -48VDC Genset with PMG Technology (10-30 KW)
• Variable Speed Engine (LPG)
• Deep Cycle Batteries (Pzs Or Lithium Technology) – Up to 2000 AH
• Hybrid Controller for Complete System Management
• Plug & Play with Renewable Energy Sources (Solar PV/WIND)
• Integrated Fuel Tank with Anti-siphoning System
• Sand Filters, Sound & Weatherproof Canopy Up to 70 dBA @ 1m
• Anti-theft Devices: Armoured Doors to Prevent Access with Crowbar, Safety Cage for Charging Batteries, Steel Belt for Starter Battery
• Remote Monitoring System Software Package is Integrated for Remote Access & Control
• Integrated Cooling System, Safety Locks, Emergency Stop Push Button

NAFFCO's UL-listed, and FM-approved fire pumps combine the stringent quality measures of UL, FM, and NFPA standards with our proven experience in the fire protection field to provide you with reliable solutions for your firefighting pump needs.

We can provide you with a full range of services, from engineering support through field setup and maintenance.

Prior to shipping, each pump set is tested in our factory in accordance with UL, FM, and NFPA standards. These pumps have a one-year guarantee, subject to regular terms and conditions.

NAFFCO also offers custom-designed vertical turbine fire pumps where UL and FM approvals are not mandatory. NVT Series fully complies with NFPA Standards.

Applications
Structural Fire Fighting, Industrial Fire Fighting.

Materials
• Outer Shell: Nomex® III A, Navy Blue /Gold, 195 Gsm
• Moisture Barrier: EPTFE Coated On Non-Woven Nomex/ Kevlar Carrier – 105 Gsm
• Thermal Liner: Non-Woven Nomex/ Kevlar Quilted With Aramid/Viscose Fabric, 70 Gsm + 120Gsm
• “H” Style suspender (Removable)
• 2” Reflective Liners

This system has been designed and certified to provide maximum glazed areas with the minimum profile view and to achieve the maximum wall height. This system guarantees comprehensive fire performance under the most severe fire conditions and provides multiple design possibilities. Available in galvanized steel powder-coated finish. This system can be combined with any door system belonging to the NAFFCO Steel fire range. Tested and certified for E (Integrity), EW (Integrity & radiation) classification, and up to 120 minutes of fire resistance, according to European standard EN 1364-1.

NaviLens is an innovative universal digital signage system that makes spaces more accessible and allows users to find
their way around and obtain information tailored to their needs. The system is based on a powerful computer vision
algorithm that detects the markers or codes installed in a space, allowing the user to read them quickly and efficiently by simply using their mobile device.

• Long scanning distance: 12 times further than barcodes and QR.
• No need to focus.
• Wide detection angle: Up to 160 degrees.
• Ultra-fast (1/30 second) and on-the-go reading capability.
• Detection in all light conditions.
• Multiple reading: Over 200 codes simultaneously.
• High information storage capacity.
• Accurate information about distances (cm and inches).
• CRC protection.
